R210 Laser Particle Counter External Vacuum Systems Pharmaceutical Standard Remote

  • R210 Laser Particle Counter External Vacuum Systems Pharmaceutical Standard Remote
  • R210 Laser Particle Counter External Vacuum Systems Pharmaceutical Standard Remote
  • R210 Laser Particle Counter External Vacuum Systems Pharmaceutical Standard Remote
Place of Origin China
Brand Name Zetron
Certification ISO21501-4
Model Number R210
Minimum Order Quantity 1
Packaging Details alloy case
Delivery Time 5-7 days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Remote Particle Counter Flow Rate (2.83L/min）
Explosion-proof Laser Diode Protection Grade IP65
Size 120 * 65 * 132 Mm Weight 0.6 Kg
Highlight

external vacuum systems laser particle counter

,

pharmaceutical standard laser particle counter

,

remote laser air particle counter
Leave a Message
Product Description
R Series
Remote Airborne Particle Counter
OVERVIEW



R Series Remote particle counter is used to install one or more monitoring points according to the actual situation on-site, and the measured data will be directly displayed on the display screen of each monitoring point.
R Series particle counter has three indicators: power indicator, communication indicator, measurement status indicator
If an abnormality occurs during real-time monitoring, the monitoring points can be quickly notified, which makes remote monitoring or monitoring in the process restricted area more convenient.



FEATURES & BENEFITS



1.Particle size channels: 0.3um-25um (optional)
2.Sampling flow rate: 1CFM (28.3LPM) or 0.1CFM (2.83LPM) (optional)
3. Three indicators: power indicator, communication indicator, measurement status indicator
4.RS485 (Modbus), 4-20mA, WIFI, LORA, TCPIP, and other signal output options
5. Long-life service with imported laser diodes and vacuum pumps
6. Displayed intuitive and clear with 2.4 inch OLED
7. 316 stainless steel casing can be customized



SPECIFICATION



Model
R200 (2.83L/min)
R300 (28.3L/min)
R210 (2.83L/min)
R310 (28.3L/min)
R310P
(28.3L/min)
Channel sizes
Two Channels: 0.5μm,5.0μm
Three Channels: 0.3μm,0.5μm,5.0μm
Four Channels: 0.3μm,0.5μm,1.0μm,5.0μm
Six Channels: 0.3μm,0.5μm,1.0μm,2.0μm,3.0μm,5.0μm(Customizable)
Display
X
Customizable
2.4 inch OLED
Display
2.4 inch OLED
Output
RS485(modbus)
RS485(modbus) or TCPIP(modbus)
(TCPIP has no extended output)
RS485(modbus)
Extended Output
X
4-20mA(2 channels); 0-5V(2channels)
Relay(2channels); WiFi; LORA
Power Supply
12-24V
12-24V(RS485(modbus))
12-24V,48V Standard POE(TCPIP(modbus))
Pump
External pump
Built-in pump(R210)
External pump(R310)
Built-in pump
Weight & Size
0.2-0.3Kg
106.5×76×49(mm)
0.9Kg
135×120×60(mm)
2.6-2.8Kg
217×250×138(mm)



R210 Laser Particle Counter External Vacuum Systems Pharmaceutical Standard Remote 0

R210 Laser Particle Counter External Vacuum Systems Pharmaceutical Standard Remote 1

R210 Laser Particle Counter External Vacuum Systems Pharmaceutical Standard Remote 2

APPLICATION



Particle Counters are feature-rich instruments that are ideal for spot-checking inside of your critical environments or Indoor Air Quality applications. With its compact size, weight, and sleek handle, you can easily utilize this unit.

These units provide immediate results that allow you to proactively monitor your environment.
It's widely used in Automotive Manufacturing; Coating Processes; Paint Booth; Aerospace Flight and Space; Hardware Manufacturing; Flat Panel Display Manufacturing; Medical Device Manufacturing
Electronic Industry (semiconductor factory, precision machinery production and processing, etc); Food Hygiene Industry (dairy products, plastic meat food, seasoning food, agricultural products, etc); Filter Manufacturers, inspection filter quality and efficiency, etc; and other areas of precision processing, precision testing required Clean Room (area), and other testing needs.

R210 Laser Particle Counter External Vacuum Systems Pharmaceutical Standard Remote 3

FAQ



Q: What are your terms of payment?
A: We accept trade assurance, western union, Visa master card, and tt.
Trade assurance can protect you, when you confirm the product then the money into my account.

Q: When do you reply to messages?
A: We will reply to your inquiry within 24 hours.

Q: What is the warranty for your product?
A: Warranty: 12 months, Lifetime maintenance

Q: When do you send the products? And how do you send it?
A: For the small order, we will send out the goods within 5 days, If have stock, we will send it immediately.
We send them by ups, FedEx, TNT, or DHL. For big orders, the normal is 20 days will finish.

Q: Do you accept OEM or revised logo, color, model, and size?
A: Yes, we accept OEM for the qualified buyer. We can make the products according to customers' personal requirements.

Q: How about the quality of the management?
A: We have a complete quality control system, all of our products will be fully pre-inspection by QC departments before shipping to you. We have the certification of ISO, CE we could send the certification test of our company to you.

Q: How about your after-sale service?
A: After sending, we will track the products for you, until you get the products.
When you get the goods, test them, and give me feedback.
If you have any questions about the problem, contact us, and we will offer the solve way for you.
