ZP800-O3 Circulation Type Ozone Gas Detector Compatible PLC DCS And Other Control Systems

  • ZP800-O3 Circulation Type Ozone Gas Detector Compatible PLC DCS And Other Control Systems
Place of Origin China
Brand Name Zetron
Certification CE, ISO13485, ISO9001
Model Number ZP800-O3
Minimum Order Quantity 1
Packaging Details paper carton
Delivery Time 3-7 days
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 1000 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Working Voltage 12-36V DC Power Supply Ozone Concentration In Air Detection Principle Electrochemical
Response Time ≤ 30 Seconds DisSignal Outputplay Mode 4～20mA 2-wire Standard Current (load 1500 Ohms)
Recovery Time ≤60 Seconds Weight About 1.5Kg
Highlight

circulation type ozone gas detector

,

electrochemical ozone gas detector
Leave a Message
Product Description

ZP800-O3 Ozone Gas Detector

OVERVIEW



ZP800-O3 0-50ppm Circulation Type Ozone Gas Detector Monitor ozone gas concentration in the environment or in the pipeline. Full software automatic calibration function, zero calibration function, make gas monitoring more accurate and reliable With temperature compensation.Adopt British sensor, can be non-contact operation and maintenance instrument Compatible with various control alarms, PLC, DCS and other control systems.



FEATURE



ZP800-O3 can realize the compensation of gas concentration under different temperature environment One or two switching signals can be output to drive external devices such as exhaust fans or solenoid valves.
Remote monitoring can be achieved, explosion-proof design, fast, reliable, stable; Ex d II CT6 full software automatic calibration function, the machine has a total of three standard keys to achieve a single person single-point field maintenance.
Working voltage: 12-36V DC power supply



PARAMETER



Detecting gas Ozone concentration in air
Detection principle electrochemical
Detection method Circulation type
Measuring range 0-50ppm
Resolution 0.01ppm(0-50ppm);
Accuracy ±3%FS
Display mode Liquid crystal display
Response time ≤ 30 seconds
Recovery time ≤60 seconds
Explosion-proof mark ExdⅡCT6
Explosion-proof connection thread 3/4" NPT
Signal output 4～20mA 2-wire standard current (load 1500 ohms)
Transmission distance 1100m (Rvv0.75 square mm shielded cable)
Operating temperature -20℃～+50℃
Relative humidity 10% ~ 95% RH (non-condensing)
Power source 24VDC±12VDC
Weight about 1.5Kg
