Zetron PTM100-AQ Air Quality Analyser PM0.3/PM0.5/PM1.0/PM2.5/PM5.0/PM10.0 For Emission Pollution

  • Zetron PTM100-AQ Air Quality Analyser PM0.3/PM0.5/PM1.0/PM2.5/PM5.0/PM10.0 For Emission Pollution
Place of Origin China
Brand Name Zetron
Certification CE, ISO13485, ISO9001
Model Number PTM100-AQ
Minimum Order Quantity 1
Packaging Details paper carton
Delivery Time 3-7 days
Payment Terms T/T,Western Union, MoneyGram
Supply Ability 10000 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Gas Monitor Test Item PM10：(0~1000)ug/m3，PM2.5:(0~1000)ug/m3，SO2：(0~500)ppb，NO2：(0~500)ppb，O3: (0~500)ppb，CO: (0~4000)ppb，TVOC: (0~2000)ppb, PM2.5/PM10 0-1000μg/m3，Temperture-40℃~+120℃，Humidity 0-100%RH
Material Plastic Size 260*230*120mm
Weight 3.7kg Warranty 1 Years
Highlight

Zetron Air Quality Analyser

,

Emission Pollution Air Quality Analyser

,

Portable Pm10 Pm2 5 Pollution Analyzer
Leave a Message
Product Description
PTM100-AQ Air Quality Monitoring Analyzer
OVERVIEW



PTM100-AQ is a portable, full-featured air quality monitoring analyzer. It is widely used in air quality monitoring and emission pollution monitoring. It can be equipped with 1-9 gas sensors plus 1 dust sensor and 1 temperature& humidity sensor, which can detect gas, dust concentration, temperature, humidity and dew point at the same time. PM0.3, PM0.5, PM1.0, PM2.5, PM5.0, PM10.0 can be detected at the same time to meet a variety of detection needs. SKY8000-AQ focuses on the accuracy of air quality detection and user experience. It support RS485 s ignal transmission, with datalog functions, through wireless d ata transmission, the measurement data can be transmitted to the cloud platform in real time.



Accurate and reliable

  • Using world top brand sensors, the test results are more reliable and can be certified by third-party authorities
  • Multiple industrial pump gas sampling, ten grades of pumping flow rate for selection.
  • Gas detection flow can be customized according to different testing environments.

Multi-display mode

  • Single curve, multi-curve, data, and other concentration display modes are switchable
  • Various gas concentration units can be shifted freely

Comprehensive functions

  • Modular internal structure, supporting 1-18 gas detection requirements
  • Monitor the temperature, humidity at the same time(Optional)
  • Bluetooth, ZIGBEE, WIFI, GPRS, and other wireless communication modes are selectable(Optional)
  • The analyzer can be equipped with an internal printer or external Bluetooth printer, to realize the mobile print function(Optional)
  • High temperature, high humidity environment measurement(Optional)

Data logging

  • Large capacity quick storage function, storage space can be customized
  • With an independent SD memory card, historical tested data can be viewed and deleted

Mobile recharging and long operation time

  • High capacity of lithium polymer rechargeable battery, super long service life and standby time
  • Mini-USB charging interface design with common data cable and mobile power can be charged anytime, anywhere

High-quality material

  • 3.5-inch HD LCD screen with resolution 320* 480, beautiful and useful menu interface
  • Selected aviation wear-resisting material, suitable for various kinds of industry environment
SPECIFICATION



Weight 3700g
Size (H x W x D)260*230*120mm
Sensors PM10:(0~1000)ug/m3,PM2.5:(0~1000)ug/m3,SO2:(0~500)ppb,NO2:(0~500)ppb,O3: (0~500)ppb,CO: (0~4000)ppb,TVOC: (0~2000)ppb, PM2.5/PM10 0-1000μg/m3,Temperture-40℃~+120℃,Humidity 0-100%RH
Detection principle Electrochemical(CO, O2,NOx, SO2), Laser(PM2.5/10), Thermosensitive(Tem), Humidity Sensitivity(Hum)
Battery Large capacity rechargeable lithium battery,5400mAh/11.1V(internal printer type)or 10000mAh/3.7V (external printer type)working hours are more than 32h with single gas and 24h with six gases together
Precision ≤±2%F.S. (higher precision is available)
Response Time ≤10S
Zero shift ≤±1%(F.S./year)
Display Formula, gas concentration data, measurement trend curve, gas curve, battery, time. Optional: temperature,humidity, pump condition, wireless status, printer status
Temperature -20℃～50℃
Humidity 0-95%RH (non-condensing)
Explosion-Proof Ex ic IIC T3 Gc
Degree of protection IP65
Screen 3.5-inch hd LCD screen with resolution 320* 480
Pump flow rate 10 grades adjustable, flow range: 0-500 cc/Min.
Alarm Buzzer, red LED and alarm status on the display, fault alarm, pump abnormal alarm, low battery alarm
Data storage Independent SD memory card, Max.32G, measurement data can be record automatically, customizable record time interval.
Approval CE, CNEX explosion proof certificate, CMC(China Metrology Certification)
Warranty 12 months

Industry Application:Park, woodland, Municipal Engineering, Ports, warehousing, airports, Railway tunnel, Community, school, hospital, other urban construction
