Place of Origin	China
Brand Name	Zetron
Certification	CE, ISO13485, ISO9001
Model Number	MS104K-M
Minimum Order Quantity	1
Price	329-345USD
Packaging Details	paper carton,15X10X5cm,4kg
Delivery Time	3-7 days
Payment Terms	T/T, Western Union, MoneyGram
Supply Ability	1000 set/month

Product Name	4 In 1 Portable Personal Safety Protection Gas Detector O2 H2S CO LELL	Model Number	MS104K-M
Usage	Industrial, Laboratory, Other	Detecting Gas	Can Be Customized Upto 500 Gases 16 At A Same Time
Alarm Type	Vibration+Sound+Light Alarm	Sensor	Imported High-precision Sensor
Sampling Method	Pump And Diffusion Sampling	Response Time	T90<20s
Size	90×70×38mm(L×W×H)	Weight	200g
Highlight	LEL Portable Multi Gas Detector , Combustible Gas Portable Multi Gas Detector , 4 In 1 Portable Gas Analyser

Delection Gases	1-4 gases(Carbon monoxide CO,hydrogen sufide H2S,oxygen O2,flammable gas Ex,carton dioxide CO2 VOC,etc) Depends on site environment and user needs
Gas Ranges	0-1000,5000,10000ppm.100%Vol,100%LEL.Depends on site environment and user needs
Resolution	0.001ppm (0-10ppm high precision) 0.01ppm (0-10 ppm) 0.01ppm (0-100 ppm) 0.1ppm (0-1000 ppm) 1ppm (0~5000 ppm and above) 0.1%LEL:0.01%Vol
Unit Display	Optional units:umol/mol ppm,mg/m3,%Vol,%LEL
Gas Sensor Principle	Electrochemistry,catalytic combustion,infrared,thermal conductivity,semiconductor,PID photoionization,etc.Depending on the range,application and user needs
Sensor Life	Electrochemistry 2-3 years,catalytic combustion 2-3 years,infrared 5-10 years,thermal conductivity 2-5 years, PID 2-3 years
Detection	Diffusion/pumping type,standard configuration: external pump
Display	2 inch LCD
Display Content	Real-time concentration,unit,gas name,alarm status,time,storage,communication status,power,charging status,etc
Detection Accuracy	Typical accuracy≤±3%FS
Response Time	T90≤ 20seconds(general)
Working Power Supply	DC7.4V
Battery Capacity	7.4V,1400mAh Rachargeable polymer battery,without overcharge,overdischarge,overvoltage,short circuit and oveheating protection funchions
Operating Hours	More than 100 hours (Diffusion type,non-catalytic sensor)
Alarm Volume	More than 90dB
Usage Environment	Temperatune:-20℃-+50℃,can be customized-40℃+70℃,relative humidity:10-95%RH
Communicalion Interfaoe	Standard Type-C port for communicafion,standard cradle charging base (Fully charged in 2 hours)
Data Storage	Standard capacity 200,000 data recording, supports local viewing,detection or data export,and the storage time interval can be set arbitrarily
Language	Chinese or English optional,defaut Chinese interface
Explosion-proof Type	Intrinsically safe Exia II CT4 Ga,Atex certificate
Protection level	IP68
Dimension	907038mm(L*WxH)
Weight	About 380g
Standard Accessories	Instructions,certficate,USB Charger (including data cable),charging dock,instrument case,external pump caltbration cover),fiter individual

MS104K-M 4 In 1 Portable Gas Analyser O2 H2S CO Combustible Gas/LEL Multi Gas Detector

LEL Portable Multi Gas Detector

Combustible Gas Portable Multi Gas Detector

4 In 1 Portable Gas Analyser
