N2O4 Single Gas Monitor Portable Diffusion Sampling Type
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Protable Single Gas Detector | Model Number | MS104K-S1 |
|---|---|---|---|
| Type | Biogas Analyzer | Detecting Gas | CO, CO2, O2, H2S,EX |
| Display Mode | 1.7inch LCD | Sensor Type | Electrochemical Sensor,IR Sensor And Etc |
| Unit | Ppm, Mg/m3, LEL,VOL | Detection Range | 0-100ppm,0-100%LEL,0-100%VOL,depending Onrequirement |
| Sampling Type | Diffusion | Size | 86×62×39mm(L×W×H) |
| Weight | 200g | ||
| Highlight | N2O4 single gas monitor,Diffusion Sampling single gas monitor,N2O4 portable single gas detector |
||
Product Description
MS104K-S1 Protable Single Gas Detector
OVERVIEW
Meet the MS104K-S1, your solution for a maintenance-free single gas detection system that excels in reliability, user-friendliness, and economic efficiency. This detector is invaluable for worker safety and compliance, offering a robust two-year protection plan with no need for calibration, sensor or battery replacements, and no charging required. Certified by IECEx, ATEX, and CNEX, the MS104K-S1 adheres to strict safety standards, ensuring the utmost quality and reliability for worker protection. Its compact and sturdy build allows for easy attachment to work attire or caps using alligator clips. It effectively detects a variety of combustible and toxic gases, including LPG, CH4, carbon monoxide, hydrogen sulfide, and sulfur dioxide, with customization available for additional harmful gases. Widely adopted in sectors like petroleum, petrochemical, metallurgy, and chemicals, it’s a crucial tool for gas detection and safeguarding employees.
FEATURES
1. Could test more than 100 gas types, especially with lR sensor forCO2.CH4.LPG,LNG combustious gas detection
2. Standby time up to 2 years, no need to replace the battery
3. Maintenance free: one button to work continuously-no calibration, nosensor replacement, no battery charging
4. With self-test function, improve safety by automatic self-test
5. Light, Sound & Valibration alarm.90dB@30cm
6. Fire-resistant, anti-static and anti-frequency radiation
7. With data storage function, not less than 100000pieces
8. Infrared communication interface
9. With human fell-down alarm function.
10. 1.7inch LCD display with backlit function
11. Atex,lEcex, Sil3 and lP68 certified
2. Standby time up to 2 years, no need to replace the battery
3. Maintenance free: one button to work continuously-no calibration, nosensor replacement, no battery charging
4. With self-test function, improve safety by automatic self-test
5. Light, Sound & Valibration alarm.90dB@30cm
6. Fire-resistant, anti-static and anti-frequency radiation
7. With data storage function, not less than 100000pieces
8. Infrared communication interface
9. With human fell-down alarm function.
10. 1.7inch LCD display with backlit function
11. Atex,lEcex, Sil3 and lP68 certified
APPLICATION SCENES
MS104K-S1 is widely used in petroleum,petrochemical, metallurgy,chemical and other industries for gasdetection and personnel protection.
SPECIFICATION
| Data Sheet | |
| Detection Gas | carbon monoxide CO,hydrogen sulfide H2S,oxygen O2,combustible gas Ex,carbon dioxide CO2,etc. |
| Detection Range | 0-100ppm,0-100%LEL,0-100%VOL,depending on requirement |
| Unit | ppm,mg/m3,LEL,VOL |
| Sensor Principle | Electrochemical sensor,IR sensor and etc |
| Sampling Type | Diffusion |
| Display | 1.7inch LCD |
| Display content | real-time concentration,alarm,power,charging status concentration unit,gas name,etc |
| Accurancy | ≤±3%FS |
| Responding time | T90≤30S |
| Power supply | DC3.6V |
| Battery capacity | 1600mAh energy battery,no charging,working time 1-2 years |
| Working Environment | Temperature:-20℃~+50℃,can be customized -40℃~+70℃ Relative humidity:10-95%RH |
| Communication | nfrared,optional communication base for communication, manual calibration and export of data |
| Language | English |
| Explosion-proof | Exia I CT4Ga,Sil3,Atex |
| Protection Leve | IP68 |
| Size | 87x63x32mm |
| Weight | 200g |
| Standard Accessories | calibration cover(diffusion type),instructions,certificate packaging box |
| Optional | communication base (TYPE-C interface) |
