MS600-L Laser Methane Remote Detector High Performance

  • MS600-L Laser Methane Remote Detector High Performance
  • MS600-L Laser Methane Remote Detector High Performance
  • MS600-L Laser Methane Remote Detector High Performance
  • MS600-L Laser Methane Remote Detector High Performance
  • MS600-L Laser Methane Remote Detector High Performance
  • MS600-L Laser Methane Remote Detector High Performance
Place of Origin China
Brand Name Zetron
Certification CE, ISO13485, ISO9001,CE， Atex, SIL3
Model Number MS600-L
Minimum Order Quantity 1
Price $100-$5000
Packaging Details paper carton
Delivery Time 3-7 days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 1000 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Laser Methane Remote Detector Model Number MS600-L
Operating Power Supply DC3.7 V*2 Display LCD
Protection Class IP65 Detection Range Depends On The Site Environment And User Needs
Dimension Length 201 *Diameter 54 MM Weight Approx. 350g
Highlight

MS600-L Methane Remote Detector

,

MS600-L Laser Methane Remote Detector

,

Remote Laser Methane Detector
Leave a Message
Product Description

MS600-L Remote Laser Methane Gas Detector



OVERVIEW



The Remote Detector MS600-L Remote Laser Methane Gas Detector consists of a transmitter unit and a receiver unit that are integrated into a compact housing. When it detects a gas leak in a remote area, the transmitter emits a laser beam to a distant reflector. As the laser beam passes over possible leaks in the area, the receiver receives the reflected light as a feedback signal for processing and calculation.The JJY150 / JJY100 utilises TDLAS (Tunable Diode Laser Absorption Spectroscopy) technology to provide accurate and instantaneous results of the cumulative methane concentration in the area, triggering alarms when methane concentration exceeds alarm levels.



FEATURES



  • The remote detector can be continuously used o 8 hours.
  • In shutdown state, standby time will last more than 60 days.
  • Protection class IP65, corrosion resistance, drop resistance
  • Easy to operate by using only one button.
  • Waterproof housing design, suitable for industrial site use.
  • The remote detector has a built-in Bluetooth module (optional), which can communicate with smart phone in real time.



APPLICATION



The detector is widely used in petroleum, chemical industry, environmental protection, metallurgy, refining, biochemical medicine, agriculture, fire control, archaeology and other industries and places that need safety detection of toxic and harmful, explosion.



PARAMETER



Size 190mm*φ54mm Material 7075 aviation aluminum alloy
Weight 350g Protection Leve IP66
Detection Gas Methane Working Time Min 20 hours
Response Time 0.03s at 50 meters Accurancy ±10%
Detection Range 0-50000ppm.m Resolution 5ppm.m
Detection Distance Max 50 meters Laser Class Detection Laser:Class I
Working Temperature -20~50℃   Indicate Laser:Class IIA
Working Pressure 40-160kpa Working Voltage 5V
Working Humidity 0-98%RH Working Current 1A
