CH4 Zetron ZW-G200 Laser Methane Gas Detector Natural Gas Leak Detector

ZW-G200 Laser Mathane Gas Detector Natural Gas Leak Deatector

The remote detector ZW-G200 Remote Laser Methane Gas Detector is composed of a transmitter unit and a receiver unit, the two units are integrated in a compact housing. When it probes gas leakage in a remote area, the transmitter emits a laser beam to a distant reflector the area. While the laser beam passes through the possible leakage point in the area, the receiver receives the reflected light as the feedback signal for processing and calculation. Utilizing TDLAS ( Tunable Diode Laser Absorption Spectroscopy) technology, JJY150 / JJY100 can accurately and instantaneously provide the cumulative methane concentration results in the area, and trigger the alarm if the methane concentration is above alarm level.

• SO,CE,FCC, ROHS, CNEX Approved
• High resolution & Fast responding
• Principle: Laser Spectroscopy
• Detection distance: 150-200 meters
• Scope automatically powers on when turned on
• No need for regular calibration, maintenance free
• Ex ib IIB T4 Gb
• IP65


​

Detection Gas	Methane CH4
Detection principle	Laser Spectroscopy
Detection distance	Max 200 meters
Measuring range	0-65535ppm.m
Resolution	1ppm.m
Accuracy	±5%
Respond time	0.01s
Gas Detection Effective Distance	0.5~50m/100m/150m/200m
Display	colorful screen, LCD display
Sensor lifetime	5-10 years
Alarm	LA 100ppm.m; HA 2000ppm.m(adjustable)
Alarm mode	digital value, curve indication, sound+light+vibration alarm
Protection level	IP65
Product Size	172.5mmx216mmx77.5mm
Weight	750g
Protection grade	Ex ib IIC T4 Gb
Working environment	-20ºC~+50ºC, ≤95%RH (non-condensing occasions)
Laser class	Detection laser near infrared (1650nm) laser safety level ClassIIR Indicate laser green (532nm) laser safety level ClassIIR
Working condition	(-30~55)ºC; ≤93%RH
Working pressure	80kPa~116kPa
Storage temperature	(-40~60)ºC
Battery	rechargeable Li-ion battery, 5000mAh, at least 500 recharging times
Working time	>10 hours
Working voltage	(3.7~4.2)V DC
Warranty time	1 year

​

1. Places inaccessible to personnel such as overhead pipelines and narrow spaces;

2. Indoor places with windows, such as residential kitchens and laboratories that use gas, can be detected directly through the windows;

3. Finding leaks of buried pipelines.
